LOC-22AJPL-MW(20/25/30) MCCT(35/40/50)D - 4-PACK LED BACKLIT PANEL 2X2, MULTI-WATTAGE 20W/25W/30W 125LM/W, MULTI-CCT 3500K/4000K/5000K, 0-10V DIMMING, AC120-277V

(0)No Reviews yet
SKU: PL0194-415
SKU: LOC-22AJPL-MW(20/25/30)MCCT(35/40/50)D
Wattage: Multiple Wattage, 20W, 25W, 30W
CCT: 3500K, 4000K, 5000K, Multiple Color Temperature
Voltage:120-277Vac
Lumen:2001 - 3000, 3001 - 4000

This item is IN STOCK

Warehouses, schools, factories, offices, supermarkets, logistic centers, exhibition halls and more.

• Samsung 2835 LED Chips
 Glare-free / flicker-free
• Steel and Aluminum frame
• PMMA lens material to prevent yellowing



  • Multi Wattage: 20W, 25W and 30W
  • Default Wattage: 30W
  • Multi CCT: 3,500K, 4,000K and 5,000K
  • Default CCT: 5,000K
  • 20W: 2,500LM 125LM/W
  • 25W: 3,125LM 125LM/W
  • 30W: 3,750LM 125LM/W
  • Power Factor: 0.9
  • CRI: 83.1
  • THD: 15%
  • 120-277Vac, 50/60Hz
  • 0-10V dimming
  • IP20 rated
  • 120° beam angle
  • 50,000 hours lifetime | 5 year limited warranty
